PRELIMINARY SPECIFICATIONS
SEYI 4 POINT LINK MOTION DUAL CRANK STRAIGHT SIDE MECHANICAL PRESS (NEW)
MODEL SLG4-1100
1100 TON CAPACITY
13.78" STROKE
43.31" DIE HEIGHT, BOLSTER TO SLIDE (SDAU)
13.78" SLIDE ADJUSTMENT
157.48" LR X 61.02" FB SLIDE AREA
157.48" LR X 61.02" FB BED AREA (DUAL ROLLING BOLSTERS)
78.74" W X 39.37" H WINDOWS
20-40 SPM VARIABLE
EQUIPPED WITH
WINTRISS WPC200 PRESS CONTROL
SMART PAC PRO AUTOMATION PACKAGE
INCLUDING AUTOSETPAC4, DIPROPAC16, PROCAMPAC16
33T CAPACITY EACH DUAL ROLLING BOLSTERS (REAR EXIT, T-CROSS)
25.20" FLOOR TO TOP OF BOLSTER
9.84" BOLSTER THICKNESS
HYDRAULIC CLAMPS ON SLIDE
26,400 LBS COUNTER-BALANCE CAPACITY
125 HP MAIN MOTOR
APPROXIMATE OVERALL HEIGHT 299"
APPROXIMATE WEIGHT 708,000 LBS
THIS IS A NEW PRESS, CALL FOR DETAILS
Specifications Subject To Verification; Subject To Prior Sale & Price Change
